The AD-1616 is a DSP Matrix for distribution of sixteen audio sources to sixteen zones. For projects that need more zones, up to four AD-1616 chassis can be combined to deliver 64 audio zones. The AD-1616 enables seamless routing of both digital and analog sources to any desired zone and features a comprehensive set of DSP controls. This includes a 5-band parametric EQ, allowing integrators to fine-tune acoustic characteristics and tailor sound to specific spaces, plus mixing and auto-ducking features facilitate seamless integration of microphones and doorbells, effortlessly prioritizing audio sources and ensuring smooth transitions. Configuration and DSP functions can be customized directly within Integration Designer or with the intuitive web GUI, enabling the AD-1616 to work in standalone mode or within another control system environment.
For amplification, we recommend pairing the AD-1616 with the RTI CP-16i 16 Channel ICEPower® Amplifier.
For projects that need more zones, up to four AD-1616 chassis can be combined to deliver 64 zones.
Learn the setup best practices with our series of short tutorials.
Included in the box:
AD-1616, power cord, rack ears (2) with screws, 4-pin Phoenix connectors (8), feet with screws (4)
Key Features
- Sixteen audio sources inputs with eight analog inputs and eight digital inputs.
- Sixteen preamp stereo audio output zones to integrate external power amplifiers or subwoofers. Preamp outputs require external amplification via RTI CP-16i or third-party audio amplifier.
- Distribute sixteen audio source inputs to sixteen zones, expandable to 64 zones by stacking up to three AD-1616 units.
- Fine-tune acoustic characteristics for each zone with a comprehensive set of DSP controls such as 5-band parametric EQ as well as mixing and auto-ducking features.
- Configure and optimize DSP and matrix settings directly within Integration Designer or with the intuitive web user interface.
- Controlled via IR, and two-way control with feedback via RS-232 and IP when installed with RTI or 3rd party control systems.
- Rack mount or free-standing installation with included rack ears and removable feet.
Overview and Programming Video
Downloads
Hi-Res Back Panel Image
See the image links below for the AD-46-100 Web GUI screens:
Specification
| Analog Sources | 8 RCA (Stereo) |
| Digital Sources | 8 Coax and 8 Optical |
| Loop Out | 8 Analog + 2 Digital |
| Amplified Zones | Preamp only. Use a CP-16i for amplification. |
| Preamp Zones | 16 Stereo (32 Channels) |
| Audio Zone Expansion | Up to 64 zones by combining up to 4 AD-1616 units |
| Input Impedance | 20kΩ |
| Analog Input | 2 Vrms Maximum |
| Analog Output | 2 Vrms Maximum. Volume controlled |
| Volume Range | 0-100 (-80dB – 0dB) |
| Digital Optical Input | Up to 192kHz/24Bit sample rate. PCM only |
| Digital Coaxial Input | Up to 192kHz/24Bit sample rate. PCM only |
| THD-N | THD+N <0.01%, 1kHz THD+N <0.05%, 20Hz-20kHz |
| SNR | >100 dB, A-weighted – input to output @ pre out |
| Frequency Response | 20Hz – 20kHz +/- 2 dB |
| Dynamic Range | >95dB A-weighted |
| Sampling Frequency | 48kHz |
| RTI or 3rd Party Control | IP (RJ45), RS-232 (RJ45) and IR (3.5mm mono) |
| AC Input Voltage | 100-240V~, 50/60Hz, 20W |
| Power Switch | Front Panel On/Off with LED power indicator |
| Mounting | Rack mount or free-standing |
| Dimensions (WxHxD) | 17.2” x 16.4” x 3.5” 437 mm x 416.5 mm x 89mm |
| Weight | 18.12 lb (8.22kg) |
| Operating Temperature | 0 to +50°C / +32 to +122°F |
| Operating Humidity | 5% to 95% Non-condensing |
| Warranty | Three Years (Parts & Labor) |
| Prop 65 Declaration | This product does not contain chemicals which are listed on California’s Safe Drinking Water & Toxic Enforcement Act of 1986. This Act, commonly known as Proposition 65 (Prop 65), establishes a list of chemicals which the state of California’s risk assessment process has determined to present a risk of cancer, birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
All features and specifications subject to change without notice.
